Gamma-ray Burst 190824A

(All information courtesy of the instrument teams.)

Previous IAU Circulars

none

Results of Observations

GCN/BACODINE POSITION NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:46:58 UT
NOTICE_TYPE:     Swift-BAT GRB Position
TRIGGER_NUM:     922107,   Seg_Num: 0
GRB_RA:          215.329d {+14h 21m 19s} (J2000),
                 215.638d {+14h 22m 33s} (current),
                 214.546d {+14h 18m 11s} (1950)
GRB_DEC:         -41.902d {-41d 54' 07"} (J2000),
                 -41.991d {-41d 59' 28"} (current),
                 -41.674d {-41d 40' 26"} (1950)
GRB_ERROR:       3.00 [arcmin radius, statistical only]
GRB_INTEN:       4112 [cnts]    Image_Peak=244 [image_cnts]
TRIGGER_DUR:     1.024 [sec]
TRIGGER_INDEX:   151     E_range: 25-100 keV
BKG_INTEN:       20085 [cnts]
BKG_TIME:        53184.53 SOD {14:46:24.53} UT
BKG_DUR:         8 [sec]
GRB_DATE:        18719 TJD;   236 DOY;   19/08/24
GRB_TIME:        53199.57 SOD {14:46:39.57} UT
GRB_PHI:          55.15 [deg]
GRB_THETA:        30.50 [deg]
SOLN_STATUS:     0x20000003
RATE_SIGNIF:     28.24 [sigma]
IMAGE_SIGNIF:    11.41 [sigma]
MERIT_PARAMS:     +1  +0  +0  +0  +2  +1  +0  +0 -21  +0
SUN_POSTN:       153.20d {+10h 12m 47s}  +11.06d {+11d 03' 37"}
SUN_DIST:         77.93 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.86d {+04h 47m 27s}  +19.59d {+19d 35' 10"}
MOON_DIST:       142.11 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.33, 17.91 [deg] galactic lon,lat of the burst (or transient)
ECL_COORDS:      227.41,-26.20 [deg] ecliptic lon,lat of the burst (or transient)
COMMENTS:        SWIFT-BAT GRB Coordinates.
COMMENTS:        This is a rate trigger.
COMMENTS:        A point_source was found.
COMMENTS:        This does not match any source in the on-board catalog.
COMMENTS:        This does not match any source in the ground catalog.
COMMENTS:        This is a GRB.
COMMENTS:        This trigger occurred at longitude,latitude = 354.07,-17.69 [deg].
COMMENTS:
COMMENTS:        NOTE: This BAT event is temporally(2.0<100sec) coincident with the FERMI_GBM event (trignum=588350802).

red DSS finding chart ps-file

GCN NOTICE

TITLE:           GCN/FERMI NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:47:03 UT
NOTICE_TYPE:     Fermi-GBM Flight Position
RECORD_NUM:      44
TRIGGER_NUM:     588350802
GRB_RA:          196.167d {+13h 04m 40s} (J2000),
                 196.451d {+13h 05m 48s} (current),
                 195.446d {+13h 01m 47s} (1950)
GRB_DEC:         -46.900d {-46d 53' 59"} (J2000),
                 -47.005d {-47d 00' 17"} (current),
                 -46.632d {-46d 37' 55"} (1950)
GRB_ERROR:       10.82 [deg radius, statistical plus systematic]
GRB_INTEN:       183 [cnts/sec]
DATA_SIGNIF:     10.00 [sigma]
INTEG_TIME:      2.048 [sec]
GRB_DATE:        18719 TJD;   236 DOY;   19/08/24
GRB_TIME:        53197.67 SOD {14:46:37.67} UT
GRB_PHI:         287.00 [deg]
GRB_THETA:        75.00 [deg]
DATA_TIME_SCALE: 2.0480 [sec]
HARD_RATIO:      0.91
LOC_ALGORITHM:   3 (version number of)
MOST_LIKELY:      73%  GRB
2nd_MOST_LIKELY:  25%  Distant Particles
DETECTORS:       0,0,0, 1,1,0, 0,0,0, 0,0,0, 0,0,
SUN_POSTN:       153.20d {+10h 12m 47s}  +11.06d {+11d 03' 37"}
SUN_DIST:         69.69 [deg]   Sun_angle= -2.9 [hr] (East of Sun)
MOON_POSTN:       71.86d {+04h 47m 27s}  +19.59d {+19d 35' 11"}
MOON_DIST:       127.58 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      305.28, 15.91 [deg] galactic lon,lat of the burst (or transient)
ECL_COORDS:      215.32,-36.46 [deg] ecliptic lon,lat of the burst (or transient)
LC_URL:          http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_lc_medres34_bn190824616.gif
COMMENTS:        Fermi-GBM Flight-calculated Coordinates.
COMMENTS:        This trigger occurred at longitude,latitude = 277.92,15.75 [deg].
COMMENTS:        The LC_URL file will not be created until ~15 min after the trigger.
COMMENTS:
COMMENTS:        NOTE: This GBM event is temporally(2.0<100sec) coincident with the SWIFT_BAT event (trignum=922107).

GCN NOTICE

TITLE:           GCN/FERMI NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:47:11 UT
NOTICE_TYPE:     Fermi-GBM Flight Position
RECORD_NUM:      58
TRIGGER_NUM:     588350802
GRB_RA:          196.233d {+13h 04m 56s} (J2000),
                 196.518d {+13h 06m 04s} (current),
                 195.512d {+13h 02m 03s} (1950)
GRB_DEC:         -46.833d {-46d 49' 59"} (J2000),
                 -46.938d {-46d 56' 17"} (current),
                 -46.566d {-46d 33' 55"} (1950)
GRB_ERROR:       6.88 [deg radius, statistical plus systematic]
GRB_INTEN:       260 [cnts/sec]
DATA_SIGNIF:     20.30 [sigma]
INTEG_TIME:      4.096 [sec]
GRB_DATE:        18719 TJD;   236 DOY;   19/08/24
GRB_TIME:        53197.67 SOD {14:46:37.67} UT
GRB_PHI:         287.00 [deg]
GRB_THETA:        75.00 [deg]
DATA_TIME_SCALE: 4.0960 [sec]
HARD_RATIO:      0.73
LOC_ALGORITHM:   3 (version number of)
MOST_LIKELY:      64%  GRB
2nd_MOST_LIKELY:  34%  Distant Particles
DETECTORS:       0,0,0, 1,1,0, 0,0,0, 0,0,0, 0,0,
SUN_POSTN:       153.20d {+10h 12m 47s}  +11.06d {+11d 03' 36"}
SUN_DIST:         69.67 [deg]   Sun_angle= -2.9 [hr] (East of Sun)
MOON_POSTN:       71.86d {+04h 47m 28s}  +19.59d {+19d 35' 12"}
MOON_DIST:       127.64 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      305.33, 15.98 [deg] galactic lon,lat of the burst (or transient)
ECL_COORDS:      215.33,-36.38 [deg] ecliptic lon,lat of the burst (or transient)
LC_URL:          http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_lc_medres34_bn190824616.gif
COMMENTS:        Fermi-GBM Flight-calculated Coordinates.
COMMENTS:        This trigger occurred at longitude,latitude = 277.92,15.75 [deg].
COMMENTS:        The LC_URL file will not be created until ~15 min after the trigger.
COMMENTS:
COMMENTS:        NOTE: This GBM event is temporally(2.0<100sec) coincident with the SWIFT_BAT event (trignum=922107).

GCN NOTICE

TITLE:           GCN/FERMI NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:47:14 UT
NOTICE_TYPE:     Fermi-GBM Ground Position
RECORD_NUM:      57
TRIGGER_NUM:     588350802
GRB_RA:          208.820d {+13h 55m 17s} (J2000),
                 209.117d {+13h 56m 28s} (current),
                 208.066d {+13h 52m 16s} (1950)
GRB_DEC:         -40.610d {-40d 36' 35"} (J2000),
                 -40.706d {-40d 42' 19"} (current),
                 -40.365d {-40d 21' 54"} (1950)
GRB_ERROR:       1.88 [deg radius, statistical only]
DATA_SIGNIF:     29.00 [sigma]
DATA_INTERVAL:   4.096 [sec]
GRB_DATE:        18719 TJD;   236 DOY;   19/08/24
GRB_TIME:        53197.67 SOD {14:46:37.67} UT
GRB_PHI:         287.00 [deg]
GRB_THETA:        86.00 [deg]
E_RANGE:         44.032 - 279.965 [keV]
LOC_ALGORITHM:   4153 (Gnd S/W Version number)
SUN_POSTN:       153.20d {+10h 12m 47s}  +11.06d {+11d 03' 36"}
SUN_DIST:         73.04 [deg]   Sun_angle= -3.7 [hr] (East of Sun)
MOON_POSTN:       71.87d {+04h 47m 28s}  +19.59d {+19d 35' 12"}
MOON_DIST:       138.00 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      315.82, 20.66 [deg] galactic lon,lat of the burst (or transient)
ECL_COORDS:      221.80,-26.85 [deg] ecliptic lon,lat of the burst (or transient)
LC_URL:          http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_lc_medres34_bn190824616.gif
POS_MAP_URL:     http://gcn.gsfc.nasa.gov/notices_f/gbm_gnd_loc_map_588350802.fits
COMMENTS:        Fermi-GBM Ground-calculated Coordinates.
COMMENTS:        This Notice was ground-generated -- not flight-generated.
COMMENTS:        The LC_URL file will not be created/available until ~15 min after the trigger.
COMMENTS:        The POS_MAP_URL file will not be created/available until ~1.5 min after the notice.
COMMENTS:
COMMENTS:        NOTE: This GBM event is temporally(2.0<100sec) coincident with the SWIFT_BAT event (trignum=922107).

GCN NOTICE

TITLE:           GCN/FERMI NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:55:54 UT
NOTICE_TYPE:     Fermi-GBM Final Position
RECORD_NUM:      0
TRIGGER_NUM:     588350802
GRB_RA:          208.090d {+13h 52m 22s} (J2000),
                 208.385d {+13h 53m 32s} (current),
                 207.342d {+13h 49m 22s} (1950)
GRB_DEC:         -39.730d {-39d 43' 47"} (J2000),
                 -39.826d {-39d 49' 34"} (current),
                 -39.484d {-39d 29' 00"} (1950)
GRB_ERROR:       1.50 [deg radius, statistical only]
GRB_DATE:        18719 TJD;   236 DOY;   19/08/24
GRB_TIME:        53197.67 SOD {14:46:37.67} UT
GRB_PHI:         288.00 [deg]
GRB_THETA:        86.00 [deg]
E_RANGE:         44.032 - 279.965 [keV]
LOC_ALGORITHM:   41531 (Gnd S/W Version number)
SUN_POSTN:       153.20d {+10h 12m 49s}  +11.06d {+11d 03' 29"}
SUN_DIST:         72.09 [deg]   Sun_angle= -3.7 [hr] (East of Sun)
MOON_POSTN:       71.95d {+04h 47m 47s}  +19.60d {+19d 36' 09"}
MOON_DIST:       137.66 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      315.49, 21.65 [deg] galactic lon,lat of the burst (or transient)
ECL_COORDS:      220.84,-26.26 [deg] ecliptic lon,lat of the burst (or transient)
LC_URL:          http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_lc_medres34_bn190824616.gif
LOC_URL:         http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_locplot_all_bn190824616.png
COMMENTS:        Fermi-GBM Final Position.
COMMENTS:        This Notice was ground-generated -- not flight-generated.
COMMENTS:        The LC_URL file should be available by the time this FINAL notice is produced.
COMMENTS:        This notice was generated completely by automated pipeline processing.
COMMENTS:        This is likely a Long GRB.
COMMENTS:
COMMENTS:        NOTE: This GBM event is temporally(2.0<100sec) coincident with the SWIFT_BAT event (trignum=922107).

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:48:53 UT
NOTICE_TYPE:     Swift-XRT Processed Image
TRIGGER_NUM:     922107,   Seg_Num: 0
GRB_RA:          215.3041d {+14h 21m 12.9s} (J2000),
                 215.6128d {+14h 22m 27.0s} (current),
                 214.5212d {+14h 18m 05.0s} (1950)
GRB_DEC:         -41.8942d {-41d 53' 39.1"} (J2000),
                 -41.9833d {-41d 58' 59.8"} (current),
                 -41.6659d {-41d 39' 57.2"} (1950)
GRB_ERROR:       4.7 [arcsec, radius, statistical plus systematic]
GRB_INTEN:       245 [cnts]
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53277.21 SOD {14:47:57.21} UT,   77.6 [sec] since BAT Trigger Time
CENTROID_X:      328.06,  raw= 328  [pixels]
CENTROID_Y:      306.55,  raw= 307  [pixels]
ROLL:            297.41 [deg]
GAIN:            8
MODE:            3, Long Image mode
WAVEFORM:        134
EXPO_TIME:       2.50 [sec]
GRB_POS_XRT_Y:   19.93
GRB_POS_XRT_Z:   48.71
IMAGE_URL:       sw00922107000msxps_rw.img
SUN_POSTN:       153.20d {+10h 12m 48s}  +11.06d {+11d 03' 35"}
SUN_DIST:         77.91 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.88d {+04h 47m 31s}  +19.59d {+19d 35' 23"}
MOON_DIST:       142.08 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.31, 17.93 [deg] galactic lon,lat of the burst
ECL_COORDS:      227.39,-26.20 [deg] ecliptic lon,lat of the burst
COMMENTS:        SWIFT-XRT Processed Image.
COMMENTS:        The object found at this position is either a very bright burst or a cosmic ray hit.
COMMENTS:        Examine the XRT Image to differentiate (CRs are much more compact); see examples at:
COMMENTS:        http://www.swift.psu.edu/xrt/XRT_Postage_Stamp_Image_Photo_Gallery.htm .

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:48:39 UT
NOTICE_TYPE:     Swift-XRT Position
TRIGGER_NUM:     922107,   Seg_Num: 0
GRB_RA:          215.3041d {+14h 21m 12.98s} (J2000),
                 215.6128d {+14h 22m 27.07s} (current),
                 214.5212d {+14h 18m 05.09s} (1950)
GRB_DEC:         -41.8942d {-41d 53' 39.1"} (J2000),
                 -41.9833d {-41d 58' 59.8"} (current),
                 -41.6659d {-41d 39' 57.2"} (1950)
GRB_ERROR:       4.7 [arcsec radius, statistical plus systematic, 90% containment]
GRB_INTEN:       1.52e-08 [erg/cm2/sec]
GRB_SIGNIF:      15.65 [sigma]
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53277.21 SOD {14:47:57.21} UT,   77.6 [sec] since BAT Trigger Time
TAM[0-3]:        327.70 237.16 261.67 243.61
AMPLIFIER:       2
WAVEFORM:        134
SUN_POSTN:       153.20d {+10h 12m 47s}  +11.06d {+11d 03' 35"}
SUN_DIST:         77.91 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.88d {+04h 47m 31s}  +19.59d {+19d 35' 21"}
MOON_DIST:       142.08 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.31, 17.93 [deg] galactic lon,lat of the burst
ECL_COORDS:      227.39,-26.20 [deg] ecliptic lon,lat of the burst
COMMENTS:        SWIFT-XRT Coordinates.
COMMENTS:        The XRT position is 1.21 arcmin from the BAT position.
COMMENTS:        The object found at this position is either a very bright burst or a cosmic ray hit.
COMMENTS:        Examine the XRT Image to differentiate (CRs are much more compact); see examples at:
COMMENTS:        http://www.swift.psu.edu/xrt/XRT_Postage_Stamp_Image_Photo_Gallery.htm .

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:48:47 UT
NOTICE_TYPE:     Swift-XRT Image
TRIGGER_NUM:     922107,   Seg_Num: 0
GRB_RA:          215.3041d {+14h 21m 12.9s} (J2000),
                 215.6128d {+14h 22m 27.0s} (current),
                 214.5212d {+14h 18m 05.0s} (1950)
GRB_DEC:         -41.8942d {-41d 53' 39.1"} (J2000),
                 -41.9833d {-41d 58' 59.8"} (current),
                 -41.6659d {-41d 39' 57.2"} (1950)
GRB_ERROR:       4.7 [arcsec, radius, statistical plus systematic]
GRB_INTEN:       245 [cnts]
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53277.21 SOD {14:47:57.21} UT,   77.6 [sec] since BAT Trigger Time
CENTROID_X:      328.06,  raw= 328  [pixels]
CENTROID_Y:      306.55,  raw= 307  [pixels]
ROLL:            297.41 [deg]
GAIN:            8
MODE:            3, Long Image mode
WAVEFORM:        134
EXPO_TIME:       2.50 [sec]
GRB_POS_XRT_Y:   19.93
GRB_POS_XRT_Z:   48.71
IMAGE_URL:       sw00922107000msxps_rw.img
SUN_POSTN:       153.20d {+10h 12m 47s}  +11.06d {+11d 03' 35"}
SUN_DIST:         77.91 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.88d {+04h 47m 31s}  +19.59d {+19d 35' 22"}
MOON_DIST:       142.08 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.31, 17.93 [deg] galactic lon,lat of the burst
ECL_COORDS:      227.39,-26.20 [deg] ecliptic lon,lat of the burst
COMMENTS:        SWIFT-XRT Image.
COMMENTS:        The object found at this position is either a very bright burst or a cosmic ray hit.
COMMENTS:        Examine the XRT Image to differentiate (CRs are much more compact); see examples at:
COMMENTS:        http://www.swift.psu.edu/xrt/XRT_Postage_Stamp_Image_Photo_Gallery.htm .

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:50:58 UT
NOTICE_TYPE:     Swift-BAT GRB Lightcurve
TRIGGER_NUM:     922107,   Seg_Num: 0
GRB_RA:          215.329d {+14h 21m 19s} (J2000),
                 215.638d {+14h 22m 33s} (current),
                 214.546d {+14h 18m 11s} (1950)
GRB_DEC:         -41.902d {-41d 54' 07"} (J2000),
                 -41.991d {-41d 59' 28"} (current),
                 -41.674d {-41d 40' 26"} (1950)
GRB_DATE:        18719 TJD;   236 DOY;   19/08/24
GRB_TIME:        53199.57 SOD {14:46:39.57} UT
TRIGGER_INDEX:   151
GRB_PHI:          55.15 [deg]
GRB_THETA:        30.50 [deg]
DELTA_TIME:      -63.00 [sec]
TRIGGER_DUR:     1.024 [sec]
SOLN_STATUS:     0x3
RATE_SIGNIF:     28.24 [sigma]
IMAGE_SIGNIF:    11.41 [sigma]
LC_URL:          sw00922107000msb.lc
SUN_POSTN:       153.20d {+10h 12m 48s}  +11.06d {+11d 03' 33"}
SUN_DIST:         77.93 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.90d {+04h 47m 36s}  +19.59d {+19d 35' 37"}
MOON_DIST:       142.09 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.33, 17.91 [deg] galactic lon,lat of the burst (or transient)
ECL_COORDS:      227.41,-26.20 [deg] ecliptic lon,lat of the burst (or transient)
COMMENTS:        SWIFT-BAT GRB Lightcurve.
COMMENTS:
COMMENTS:        The next comments were copied from the BAT_POS Notice:
COMMENTS:        This is a rate trigger.
COMMENTS:        A point_source was found.
COMMENTS:        This does not match any source in the on-board catalog.
COMMENTS:        This does not match any source in the ground catalog.
COMMENTS:        This is a GRB.
COMMENTS:        This trigger occurred at longitude,latitude = 354.07,-17.69 [deg].

GCN Circular #25462
The Fermi GBM team reports the detection of a likely LONG GRB
At 14:46:37 UT on 24 Aug 2019, the Fermi Gamma-ray Burst Monitor (GBM) triggered and located GRB 190824A (trigger 588350802.674684 / 190824616).
The on-ground calculated location, using the Fermi GBM trigger data, is RA = 208.1, Dec = -39.7 (J2000 degrees, equivalent to J2000 13h 52m, -39d 42'), with a statistical uncertainty of 1.5 degrees.
The angle from the Fermi LAT boresight is 86.0 degrees.
The skymap can be found here: http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_skymap_all_bn190824616.png
The HEALPix FITS file, including the estimated localization systematic, can be found here: http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_healpix_all_bn190824616.fit
The GBM light curve can be found here: http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers/2019/bn190824616/quicklook/glg_lc_medres34_bn190824616.gif

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:59:03 UT
NOTICE_TYPE:     Swift-UVOT Source List
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 58"} (J2000)
POINT_ROLL:      297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53767.63 SOD {14:56:07.63} UT,   568.1 [sec] since BAT Trigger Time
FILTER:          10, White
BKG_MEAN:        3.061
N_STARS:         190
X_OFFSET:        241 [pixels]
Y_OFFSET:        657 [pixels]
X_MAX:           1200 [pixels]
Y_MAX:           1616 [pixels]
DET_THRESH:      14
PHOTO_THRESH:    8
SL_URL:          sw00922107000msufc0568.fits
SUN_POSTN:       153.20d {+10h 12m 49s}  +11.06d {+11d 03' 26"}
SUN_DIST:         77.89 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.98d {+04h 47m 55s}  +19.61d {+19d 36' 30"}
MOON_DIST:       142.03 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Source List.

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:59:22 UT
NOTICE_TYPE:     Swift-UVOT Processed Source List
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 58"} (J2000)
POINT_ROLL:      297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53767.63 SOD {14:56:07.63} UT,   568.1 [sec] since BAT Trigger Time
FILTER:          10, White
BKG_MEAN:        3.061
N_STARS:         190
X_OFFSET:        241 [pixels]
Y_OFFSET:        657 [pixels]
X_MAX:           1200 [pixels]
Y_MAX:           1616 [pixels]
DET_THRESH:      14
PHOTO_THRESH:    8
SL_URL:          sw00922107000msufc0568.fits
SUN_POSTN:       153.20d {+10h 12m 49s}  +11.06d {+11d 03' 26"}
SUN_DIST:         77.89 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.98d {+04h 47m 55s}  +19.61d {+19d 36' 32"}
MOON_DIST:       142.02 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Processed Source List.
COMMENTS:        All 4 attachments are included.

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 15:00:28 UT
NOTICE_TYPE:     Swift-UVOT Image
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 58"} (J2000)
ROLL:            297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53767.63 SOD {14:56:07.63} UT,   568.1 [sec] since BAT Trigger Time
FILTER:          10, White
EXPOSURE_ID:     588351391
X_OFFSET:        560 [pixels]
Y_OFFSET:        976 [pixels]
WIDTH:           160 [pixels]
HEIGHT:          160 [pixels]
X_GRB_POS:       720
Y_GRB_POS:       1136
BINNING_INDEX:   1
IM_URL:          sw00922107000msuni0592.fits
SUN_POSTN:       153.21d {+10h 12m 49s}  +11.06d {+11d 03' 25"}
SUN_DIST:         77.88 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.99d {+04h 47m 58s}  +19.61d {+19d 36' 39"}
MOON_DIST:       142.02 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Image.
COMMENTS:        The GRB Position came from the Window Position in the Mode Command.
COMMENTS:        The image has 2x2 binning (compression).

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 15:00:38 UT
NOTICE_TYPE:     Swift-UVOT Processed Image
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 58"} (J2000)
ROLL:            297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53767.63 SOD {14:56:07.63} UT,   568.1 [sec] since BAT Trigger Time
FILTER:          10, White
EXPOSURE_ID:     588351391
X_OFFSET:        560 [pixels]
Y_OFFSET:        976 [pixels]
WIDTH:           160 [pixels]
HEIGHT:          160 [pixels]
X_GRB_POS:       720
Y_GRB_POS:       1136
BINNING_INDEX:   1
IM_URL:          sw00922107000msuni0592.fits
SUN_POSTN:       153.21d {+10h 12m 49s}  +11.06d {+11d 03' 25"}
SUN_DIST:         77.88 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.99d {+04h 47m 58s}  +19.61d {+19d 36' 40"}
MOON_DIST:       142.02 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Processed Image.
COMMENTS:        The GRB Position came from the Window Position in the Mode Command.
COMMENTS:        The image has 2x2 binning (compression).
COMMENTS:        All 4 attachments are included.

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 14:59:52 UT
NOTICE_TYPE:     Swift-XRT Position UPDATE
TRIGGER_NUM:     922107,   Seg_Num: 0
GRB_RA:          215.3044d {+14h 21m 13.05s} (J2000),
                 215.6131d {+14h 22m 27.14s} (current),
                 214.5215d {+14h 18m 05.16s} (1950)
GRB_DEC:         -41.8943d {-41d 53' 39.4"} (J2000),
                 -41.9834d {-41d 59' 00.1"} (current),
                 -41.6660d {-41d 39' 57.5"} (1950)
GRB_ERROR:       2.3 [arcsec radius, statistical plus systematic, 90% containment]
GRB_INTEN:       1.00e-10 [erg/cm2/sec]
GRB_SIGNIF:      10.00 [sigma]
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  53724.00 SOD {14:55:24.00} UT,   524.4 [sec] since BAT Trigger Time
TAM[0-3]:        100.00 100.00 100.00 100.00
AMPLIFIER:       1
WAVEFORM:        31
SUN_POSTN:       153.20d {+10h 12m 49s}  +11.06d {+11d 03' 26"}
SUN_DIST:         77.90 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       71.99d {+04h 47m 56s}  +19.61d {+19d 36' 35"}
MOON_DIST:       142.03 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.31, 17.93 [deg] galactic lon,lat of the burst
ECL_COORDS:      227.39,-26.20 [deg] ecliptic lon,lat of the burst
COMMENTS:        SWIFT-XRT Coordinates.
COMMENTS:        This Notice was ground-generated -- not flight-generated.
COMMENTS:        This is an Update Notice -- the RA,Dec values herein supersede the previous XRT_POS Notice.
COMMENTS:        TAM values, flux and significance fields are not valid.
COMMENTS:        This position was automatically generated on the ground using
COMMENTS:        Photon Counting data telemetered via TDRSS (SPER data).
COMMENTS:        See http://www.swift.ac.uk/sper/docs.php for details.
COMMENTS:        This position was enhanced using UVOT field astrometry.
COMMENTS:        The probability that this is a serendipitous source in the
COMMENTS:        SPER window is 0.58% < P(seren) < 1.1%.

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 15:04:50 UT
NOTICE_TYPE:     Swift-UVOT Source List
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 59"} (J2000)
POINT_ROLL:      297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  54076.53 SOD {15:01:16.53} UT,   877.0 [sec] since BAT Trigger Time
FILTER:          10, White
BKG_MEAN:        3.041
N_STARS:         190
X_OFFSET:        1 [pixels]
Y_OFFSET:        417 [pixels]
X_MAX:           1440 [pixels]
Y_MAX:           1856 [pixels]
DET_THRESH:      14
PHOTO_THRESH:    8
SL_URL:          sw00922107000msufc0876.fits
SUN_POSTN:       153.21d {+10h 12m 50s}  +11.06d {+11d 03' 21"}
SUN_DIST:         77.88 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       72.03d {+04h 48m 08s}  +19.62d {+19d 37' 08"}
MOON_DIST:       142.00 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Source List.

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 15:05:04 UT
NOTICE_TYPE:     Swift-UVOT Processed Source List
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 59"} (J2000)
POINT_ROLL:      297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  54076.53 SOD {15:01:16.53} UT,   877.0 [sec] since BAT Trigger Time
FILTER:          10, White
BKG_MEAN:        3.041
N_STARS:         190
X_OFFSET:        1 [pixels]
Y_OFFSET:        417 [pixels]
X_MAX:           1440 [pixels]
Y_MAX:           1856 [pixels]
DET_THRESH:      14
PHOTO_THRESH:    8
SL_URL:          sw00922107000msufc0876.fits
SUN_POSTN:       153.21d {+10h 12m 50s}  +11.06d {+11d 03' 21"}
SUN_DIST:         77.88 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       72.03d {+04h 48m 08s}  +19.62d {+19d 37' 10"}
MOON_DIST:       141.99 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Processed Source List.
COMMENTS:        All 4 attachments are included.

GCN Circular #25463
V. D'Elia (SSDC), E. Ambrosi (INAF-IASFPA), S. D. Barthelmy (GSFC), D. N. Burrows (PSU), J.D. Gropp (PSU), N. J. Klingler (PSU), A. Y. Lien (GSFC/UMBC), F. E. Marshall (NASA/GSFC), K. L. Page (U Leicester) and D. M. Palmer (LANL) report on behalf of the Neil Gehrels Swift Observatory Team:
At 14:46:39 UT, the Swift Burst Alert Telescope (BAT) triggered and located GRB 190824A (trigger=922107). Swift slewed immediately to the burst. The BAT on-board calculated location is RA, Dec 215.329, -41.902, which is
```
   RA(J2000)  =  14h 21m 19s
   Dec(J2000) = -41d 54' 07"
```
with an uncertainty of 3 arcmin (radius, 90% containment, including systematic uncertainty). The BAT light curve shows multiple peaks with a total duration of about 120 sec. The peak count rate was ~3200 counts/sec (15-350 keV), at ~1 sec after the trigger.
The XRT began observing the field at 14:55:24.0 UT, 524.4 seconds after the BAT trigger. Using promptly downlinked data we find a fading, uncatalogued X-ray source with an enhanced position: RA, Dec 215.3045, -41.8943 which is equivalent to:
```
   RA(J2000)  = 14h 21m 13.09s
   Dec(J2000) = -41d 53' 39.3"
```
with an uncertainty of 2.3 arcseconds (radius, 90% containment). This location is 71 arcseconds from the BAT onboard position, within the BAT error circle. This position may be improved as more data are received; the latest position is available at http://www.swift.ac.uk/sper. No spectrum from the promptly downlinked event data is yet available to determine the column density.
UVOT took a finding chart exposure of 150 seconds with the White filter starting 568 seconds after the BAT trigger. No credible afterglow candidate has been found in the initial data products. The 2.7'x2.7' sub-image covers 100% of the XRT error circle. The typical 3-sigma upper limit has been about 19.6 mag. The 8'x8' region for the list of sources generated on-board covers 100% of the XRT error circle. The list of sources is typically complete to about 18 mag. No correction has been made for the expected extinction corresponding to E(B-V) of 0.12.
Burst Advocate for this burst is V. D'Elia (delia AT ssdc.asi.it). Please contact the BA by email if you require additional information regarding Swift followup of this burst. In extremely urgent cases, after trying the Burst Advocate, you can contact the Swift PI by phone (see Swift TOO web site for information: http://www.swift.psu.edu/)

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 15:06:12 UT
NOTICE_TYPE:     Swift-UVOT Image
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 59"} (J2000)
ROLL:            297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  54076.53 SOD {15:01:16.53} UT,   877.0 [sec] since BAT Trigger Time
FILTER:          10, White
EXPOSURE_ID:     588351700
X_OFFSET:        560 [pixels]
Y_OFFSET:        976 [pixels]
WIDTH:           160 [pixels]
HEIGHT:          160 [pixels]
X_GRB_POS:       720
Y_GRB_POS:       1136
BINNING_INDEX:   1
IM_URL:          sw00922107000msuni0900.fits
SUN_POSTN:       153.21d {+10h 12m 50s}  +11.06d {+11d 03' 20"}
SUN_DIST:         77.88 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       72.05d {+04h 48m 11s}  +19.62d {+19d 37' 17"}
MOON_DIST:       141.99 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Image.
COMMENTS:        The GRB Position came from the Window Position in the Mode Command.
COMMENTS:        The image has 2x2 binning (compression).

GCN NOTICE

TITLE:           GCN/SWIFT NOTICE
NOTICE_DATE:     Sat 24 Aug 19 15:06:24 UT
NOTICE_TYPE:     Swift-UVOT Processed Image
TRIGGER_NUM:     922107,   Seg_Num: 0
POINT_RA:        215.289d {+14h 21m 09s} (J2000)
POINT_DEC:       -41.883d {-41d 52' 59"} (J2000)
ROLL:            297.415d
IMG_START_DATE:  18719 TJD;   236 DOY;   19/08/24
IMG_START_TIME:  54076.53 SOD {15:01:16.53} UT,   877.0 [sec] since BAT Trigger Time
FILTER:          10, White
EXPOSURE_ID:     588351700
X_OFFSET:        560 [pixels]
Y_OFFSET:        976 [pixels]
WIDTH:           160 [pixels]
HEIGHT:          160 [pixels]
X_GRB_POS:       720
Y_GRB_POS:       1136
BINNING_INDEX:   1
IM_URL:          sw00922107000msuni0900.fits
SUN_POSTN:       153.21d {+10h 12m 50s}  +11.06d {+11d 03' 20"}
SUN_DIST:         77.88 [deg]   Sun_angle= -4.2 [hr] (East of Sun)
MOON_POSTN:       72.05d {+04h 48m 11s}  +19.62d {+19d 37' 18"}
MOON_DIST:       141.99 [deg]
MOON_ILLUM:      40 [%]
GAL_COORDS:      320.30, 17.94 [deg] galactic lon,lat of the pointing direction
ECL_COORDS:      227.37,-26.20 [deg] ecliptic lon,lat of the pointing direction
COMMENTS:        SWIFT-UVOT Processed Image.
COMMENTS:        The GRB Position came from the Window Position in the Mode Command.
COMMENTS:        The image has 2x2 binning (compression).
COMMENTS:        All 4 attachments are included.

GCN Circular #25466
J.P. Osborne, A.P. Beardmore, P.A. Evans and M.R. Goad (U. Leicester) report on behalf of the Swift-XRT team.
Using 1213 s of XRT Photon Counting mode data and 2 UVOT images for GRB 190824A, we find an astrometrically corrected X-ray position (using the XRT-UVOT alignment and matching UVOT field sources to the USNO-B1 catalogue): RA, Dec = 215.30490, -41.89382 which is equivalent to:
```
RA (J2000): 14h 21m 13.18s
Dec (J2000): -41d 53' 37.8"
```
with an uncertainty of 1.5 arcsec (radius, 90% confidence).
This position may be improved as more data are received. The latest position can be viewed at http://www.swift.ac.uk/xrt_positions. Position enhancement is described by Goad et al. (2007, A&A, 476, 1401) and Evans et al. (2009, MNRAS, 397, 1177).
This circular was automatically generated, and is an official product of the Swift-XRT team.
GCN Circular #25467
V. Lipunov, E. Gorbovskoy, V.Kornilov, N.Tyurina, P.Balanutsa, A.Kuznetsov, F.Balakin, V.Vladimirov, D. Vlasenko, I.Gorbunov, D.Zimnukhov, V.Senik, T.Pogrosheva, D.Kuvshinov (Lomonosov Moscow State University, SAI, Physics Department),
R. Podesta, C.Lopez, F. Podesta, C.Francile (Observatorio Astronomico Felix Aguilar OAFA),
H.Levato (Instituto de Ciencias Astronomicas, de la Tierra y del Espacio ICATE),
R. Rebolo, M. Serra (The Instituto de Astrofisica de Canarias),
D. Buckley (South African Astronomical Observatory),
O.A. Gres, N.M. Budnev, O.Ershova (Irkutsk State University, API),
A. Tlatov, D. Dormidontov (Kislovodsk Solar Station of the Pulkovo Observatory),
V. Yurkov, A. Gabovich, Yu. Sergienko (Blagoveschensk Educational State University)
MASTER-SAAO robotic telescope (Global MASTER-Net: http://observ.pereplet.ru, Lipunov et al., 2010, Advances in Astronomy, vol. 2010, 30L) located in South Africa (South African Astronomical Observatory) started inspect of the Fermi GRB190824.62 (trigger No 588350802, 13h 52m 21.60s , -39d 43m 48.00s, R=1.5) errorbox 19364 sec after trigger time at 2019-08-24 20:09:21 UT, with upper limit up to 18.6 mag. The observations began at zenit distance = 68 deg. The sun altitude is -49.3 deg.
The galactic latitude b = -60 deg., longitude l = 98 deg.
Real time updated cover map and OT discovered available here: https://master.sai.msu.ru/site/master2/observ.php?id=1114676
We obtain a following upper limits.
```
Tmid-T0  |      Date Time      |          Site       |             Coord (J2000)          |Filt.| Expt. | Limit| Comment
_________|_____________________|_____________________|____________________________________|_____|_______|_______|________

   19394 | 2019-08-24 20:09:21 |         MASTER-SAAO | ( 13h 50m 02.27s , -39d 55m 16.01s) |   C |    60 | 18.6 |
   19504 | 2019-08-24 20:11:11 |         MASTER-SAAO | ( 13h 47m 13.25s , -37d 54m 57.76s) |   C |    60 | 18.5 |
   19611 | 2019-08-24 20:12:57 |         MASTER-SAAO | ( 13h 54m 04.83s , -41d 55m 14.79s) |   C |    60 | 18.5 |
   19808 | 2019-08-24 20:16:14 |         MASTER-SAAO | ( 14h  0m 29.00s , -39d 54m 55.30s) |   C |    60 | 18.6 |
Filter C is a clear (unfiltred) band.
```
The observation and reduction will continue. The message may be cited.
GCN Circular #25469
C. Fletcher (USRA) and C. Meegan (UAH) report on behalf of the Fermi GBM Team:
"At 14:46:37.67 UT on 24 August 2019, the Fermi Gamma-Ray Burst Monitor (GBM) triggered and located GRB 190824A (trigger 588350802 / 190824616), which was also detected by the Swift/BAT (D'Elia et al. 2019, GCN 25463) The Fermi GBM Final Real-time Localization (GCN 25462) is consistent with the Swift position.
The angle from the Fermi LAT boresight at the GBM trigger time is 82 degrees.
The GBM light curve consists of an initial bright pulse followed by multiple peaks with a duration (T90) of about 109 s (50-300 keV). The time-averaged spectrum from T0-1.024 s to T0+107.52 s is best fit by a power law function with an exponential high-energy cutoff. The power law index is -1.38 +/- 0.06 and the cutoff energy, parameterized as Epeak, is 247 +/- 55 keV
The event fluence (10-1000 keV) in this time interval is (1.4 +/- 0.1)E-05 erg/cm^2. The 1-sec peak photon flux measured starting from T0+2.05 s in the 10-1000 keV band is 7.9 +/- 0.4 ph/s/cm^2.
The spectral analysis results presented above are preliminary; final results will be published in the GBM GRB Catalog: https://heasarc.gsfc.nasa.gov/W3Browse/fermi/fermigbrst.html
For Fermi GBM data and info, please visit the official Fermi GBM Support Page: https://fermi.gsfc.nasa.gov/ssc/data/access/gbm/"
GCN Circular #25470
A. Tohuvavohu (PSU), J.A. Kennea (PSU), K.L. Page (U. Leicester), A.P. Beardmore (U. Leicester), P.A. Evans (U. Leicester), P. D'Avanzo (INAF-OAB), M.G. Bernardini (INAF-OAB), E. Ambrosi (INAF-IASFPA) , B. Sbarufatti (PSU) and V. D'Elia report on behalf of the Swift-XRT team:
We have analysed 6.1 ks of XRT data for GRB 190824A (D'Elia et al. GCN Circ. 25463), from 524 s to 34.2 ks after the BAT trigger. The data are entirely in Photon Counting (PC) mode. The enhanced XRT position for this burst was given by Osborne et al. (GCN Circ. 25466).
The light curve can be modelled with a power-law decay with a decay index of alpha=0.64 (+/-0.04).
A spectrum formed from the PC mode data can be fitted with an absorbed power-law with a photon spectral index of 2.19 (+0.22, -0.21). The best-fitting absorption column is 1.29 (+0.25, -0.22) x 10^22 cm^-2, in excess of the Galactic value of 1.0 x 10^21 cm^-2 (Willingale et al. 2013). The counts to observed (unabsorbed) 0.3-10 keV flux conversion factor deduced from this spectrum is 4.7 x 10^-11 (1.1 x 10^-10) erg cm^-2 count^-1.
A summary of the PC-mode spectrum is thus:
```
Total column:	     1.29 (+0.25, -0.22) x 10^22 cm^-2
Galactic foreground: 1.0 x 10^21 cm^-2
Excess significance: 8.9 sigma
Photon index:	     2.19 (+0.22, -0.21)
```
If the light curve continues to decay with a power-law decay index of 0.64, the count rate at T+24 hours will be 0.030 count s^-1, corresponding to an observed (unabsorbed) 0.3-10 keV flux of 1.4 x 10^-12 (3.3 x 10^-12) erg cm^-2 s^-1.
The results of the XRT-team automatic analysis are available at http://www.swift.ac.uk/xrt_products/00922107.
This circular is an official product of the Swift-XRT team.
GCN Circular #25479
GRB 190824A: Swift/UVOT Upper Limits
K. K. Simpson (PSU) and V. D'Elia (SSDC) report on behalf of the Swift/UVOT team:
The Swift/UVOT began settled observations of the field of GRB 190824A 568 s after the BAT trigger (D'Elia et al., GCN Circ. 25463). No optical afterglow consistent with the XRT position (Osborne et al., GCN Circ. 25466) is detected in the initial UVOT exposures. Preliminary 3-sigma upper limits using the UVOT photometric system (Breeveld et al. 2011, AIP Conf. Proc. 1358, 373) for the first finding chart (FC) exposure and subsequent exposures are:
```
Filter         T_start(s)   T_stop(s)      Exp(s)         Mag

white_FC           568          718          147         >19.9
white              568         1721          389         >19.9
v                 1058         6747          196         >17.8
b                  799         1697           97         >18.9
u                  774         1672           97         >19.3
w1                 750         1647           97         >18.4
m2                 725         1622           97         >19.6
w2                 849         1742           74         >18.7
```
The magnitudes in the table are not corrected for the Galactic extinction due to the reddening of E(B-V) = 0.12 in the direction of the burst (Schlegel et al. 1998).
GCN Circular #25482
J. R. Cummings (CPI) S. D. Barthelmy (GSFC), V. D'Elia (SSDC), H. A. Krimm (NSF), A. Y. Lien (GSFC/UMBC), C. B. Markwardt (GSFC), D. M. Palmer (LANL), T. Sakamoto (AGU), M. Stamatikos (OSU), T. N. Ukwatta (LANL) (i.e. the Swift-BAT team):
Using the data set from T-230 to T+963 sec from the recent telemetry downlink, we report further analysis of BAT GRB 190824A (trigger #922107) (D'Elia, et al., GCN Circ. 25463). The BAT ground-calculated position is RA, Dec = 215.323, -41.900 deg which is
```
  RA(J2000)  =  14h 21m 17.6s
  Dec(J2000) = -41d 53' 59.5"
```
with an uncertainty of 1.7 arcmin, (radius, sys+stat, 90% containment). The partial coding was 28%.
The mask-weighted light curve shows three main peaks, each with underlying substructure. The first peak is from ~T-80 sec to T-60 sec. The second, largest, peak is from ~T-10 sec to T+50 sec, and the third peak is from ~T+85 sec to T+110 sec. T90 (15-350 keV) is 169.4 +- 5.9 sec (estimated error including systematics).
The time-averaged spectrum from T-71.9 to T+114.6 sec is best fit by a simple power-law model. The power law index of the time-averaged spectrum is 1.62 +- 0.08. The fluence in the 15-150 keV band is 8.5 +- 0.4 x 10^-6 erg/cm2. The 1-sec peak photon flux measured from T+0.12 sec in the 15-150 keV band is 5.0 +- 0.5 ph/cm2/sec. All the quoted errors are at the 90% confidence level.
The results of the batgrbproduct analysis are available at http://gcn.gsfc.nasa.gov/notices_s/922107/BA/

Back to JG's homepage

Jochen Greiner, last update: 27-Aug-2019 [Disclaimer]
